WiFi Hour Meter, Wireless Equipment Uptime, Downtime Counter

iTrixx Wireless WiFi Hour Meter – Equipment Uptime/Downtime Tracking, Automated Alerting and Reporting

Innovative WiFi Hour Meter uses ‘Internet of Things’ technology accurately monitoring equipment runtime for any powered equipment.

Linortek iTrixx wireless WiFi hour meter is an ease-of-use, WiFi enabled with MQTT protocol, custom developed hour meter that can be used to track any powered equipment cumulative usage, uptime, downtime, or as a counter, audible or visual alerts can be triggered with user definable condition when you connect a signal device to one of the relay outputs, reports can be scheduled to sent to your inbox daily, weekly or monthly or other time interval for various events. With Linortek WiFi hour meter, you can connect your offline equipment to the Internet and collect the equipment runtime data over a network or the Internet, no additional software needed and no monthly fees. It’s a simple, reliable and affordable solution for industrial, manufacturing, airport, golf course and equipment rental companies to collect runtime data for any equipment such as machinery, motorized ground equipment, golf carts, forklifts, etc.

Download iTrixx Product Brochure

iTrixx-WFMN-Di wifi hour meter Equipment Hour Meter

Benefits of iTrixx WiFi Hour Meter

Respond and resolve downtime immediately
Flexible counter activation (input voltage, digital input, analog input or relay output)
Check equipment data in real time from any internet enable device

Hardware and software for installation and operation are included
One time purchase, no subscription fees, free software update
Simple self-install solution for machinery usage remote monitoring

The WiFi Hour Meter Hardware

iTrixx-WFMN-ADI

The iTrixx-WFMN-ADi Wireless WiFi Hour Meter equipped with 2 digital inputs, 2 relay outputs, 2 analog inputs, an impact sensor, and specially designed software that functions as an hour meter. The hour recording can be triggered by different ways including digital input, analog input, or relay activation.

Buy iTrixx-WFMN-ADI in iTrixx Store

iTrixx-WFMN-DI

The WFMN-Di Wireless WiFi Hour Meter equipped with 2 digital inputs, an impact sensor, and specially designed software that functions as an hour meter. The hour recording can be triggered by the digital inputs.

Buy iTrixx-WFMN-DI in iTrixx Store

iTrixx-WFMN-Di Equipment Hour Meter wifi hour meter

The WiFi Hour Meter Software

Once you install the iTrixx on your machine and connect it to your WiFi network, it will get an IP address automatically from your router, you can use any computer on the same network for initial setup using Telnet to quickly discover equipment uptime and usage data from the the HourCollector desktop app, or send data reports via email at the frequency you prefer.

There are two meter counters built-in on the software with independent trigger. You can use one for uptime, one for downtime, or or one for each machine of your choice. With the simple-to-use commands, you can easily create tasks, reports and alerts from Telnet on your PC or download a TCP Telnet app from the app store on your phone to configure the device from any mobile devices.

Monitor Multi Wifi Hour Meter from HourMeterCollector

The HourCollector Desktop App

With Linortek Network Hour Meter, whether you are maintaining one piece of equipment or multiple pieces, you can now monitor all equipment run time data from our HourMeter Collector program on a PC. The HourMeter Collector program is special designed App that can be used to monitor multiple devices from one simple interface without the needs of logging in to the devices. It will collect the hour runtime every 2 minutes automatically by default. When you run the HourMeter Collector for the first time, it will generate a CSV_FILE folder with your Hour Meter Logs details, which you can use to import to your own management system.

Real-Time Data Acquisition

The Wifi Hour Meter is built on Linortek’s existing TCP/IP web-based product platform, with digital inputs, relay outputs, analog inputs and a specially designed software that functions as an hour meter, no 3rd party server and no monthly fees, no need to manually collect runtime data from equipment, no more white board to update or tags to fill out, equipment operating hours can be read at any time from your PC or mobile devices, receive email notification or audible/visual alerts when service is needed.

Download iTrixx Wireless Hour Meter Brochure

Linortek IoTMeter Flexible Data Collection and Access

Data Integration and Management

For anyone who needs to incorporate the hour readings into their own management database you can transfer the data automatically using a UDP broadcast or directly query the JSON output to manage equipment across single or multiple locations.

WiFi Hour Meter + MQTT

MQTT is a simple messaging protocol, designed for constrained devices with low-bandwidth. So, it’s the perfect solution for Internet of Things applications. MQTT allows you to send commands to control outputs, read and publish data from sensor nodes and much more. The new development provides a standard method of communication for iTrixx to reliably communicate data across networks with any IoT platform and applications, it makes it really easy to establish a communication between iTrixx and other devices, enables iTrixx become a standard product in IIoT arena for data acquisition.

Questions? Contact Us Today!

The Key Features

Collect Data Remotely
• WiFi enabled all-in-one system, no 3rd party server and no monthly fees
• Internet independent using your intranet
• Record time from 0 to 999,999.99 hours
• Resettable hours for using with existing equipment
• Non-resettable option available
• Two separate hour meters with independent triggers
• Multiply triggers input/relay/input voltage
• Monitor multiple equipment runtime with HourCollector desktop app

Use Data with Ease
• Automatically connect and report its current runtime data when the equipment passes within the WiFi range
• User settable data report interval (in minutes) giving you flexible control of when to get the data
• Integrate hour readings data to your own management software using a UDP broadcast or directly query the JSON output
• Built-in MQTT protocol provides a standard method of communication with any IoT platforms and applications

Products Comparison

WiFi Hour Meter vs Ethernet Hour Meter

The WiFi Hour Meter connects to the LAN through a WiFi. Prefer a Ethernet solution? We have you covered! Check our Ethernet Hour Meter if you need a device to monitor stationary equipment such as production machinery, pump, heater.

Model	iTrixx-Ultra 300	iTrixx-NHM	iTrixx-WFMN-ADi	iTrixx-WFMN-Di
Part Number	01-910-00111	01-910-00024	01-910-00060	01-910-00064
Web Server	Built- In (All Software Located on Built-in Web Server)	Built- In (All Software Located on Built-in Web Server)	Built- In (All Software Located on Built-in Web Server)	Built- In (All Software Located on Built-in Web Server)
Software Configuration	Web Browser	Web Browser	Telnet (30316 port)	Telnet (30316 port)
Desktop App	Included	Included	Included	Included
Relay Outputs	2 (Signal Relay, 2 Form C, 1A @ 30VDC, dry contact)	2 (1 FORM A 48VAC@8A Max, dry contact)	2 (Signal Relay, 2 Form C (1A @ 30VDC, 0.3A @ 125VAC, dry contact)	NA
Digital Inputs	2 Isolated mode (ISO): 5-24VDC@30mA max PULL UP mode (PU): used with a switch to activate a signal	2 Isolated mode (ISO): 5-24VDC@30mA max PULL UP mode (PU): used with a switch to activate a signal	2 Isolated mode (ISO): 5-24VDC@30mA max PULL UP mode (PU): used with a switch to activate a signal	2 Isolated mode (ISO): 5-24VDC@30mA max PULL UP mode (PU): used with a switch to activate a signal
Analog Inputs	2 Isolated 2-wire input: voltage: 5V or current 4-20mA 1 for Temp & Humid only	1 for Temp &Humid only	Isolated 2-wire input: voltage: 5V or current 4-20mA	NA
Record Time (hrs)	0 – 999,999.99	0 – 999,999.99	0 – 999,999.99	0 – 999,999.99
Data Integration	RESTful API, MQTT, XML, JSON	UDP, RESTful API, XML	JSON, UDP, MQTT	JSON, UDP, MQTT
Data Monitoring	Local or Remote	Local or Remote	Local or Remote	Local or Remote
Security Protocols	TLS, SSL	NA	TLS, SSL	TLS, SSL
Power Input	12-48 VDC or POE	12-48 VDC or POE	12-48VDC	12-48VDC
Enclosure	DIN Rail Mountable	DIN Rail Mountable	IP66/67 Polycarbonate Box	IP66/67 Polycarbonate Box
Certifications	NA	NA	FCC, CE and ROHS	FCC, CE and ROHS
Network Connectivity	Ethernet Port: 10/100Base-TX PoE	Ethernet Port: 10/100Base-TX PoE	WiFi: IEEE 802.11b/g/n 2.4GHz	WiFi: IEEE 802.11b/g/n 2.4GHz
	Buy iTrixx-Ultra 300 Now	Buy iTrixx-NHM Now	Buy iTrixx-WFMN-ADi Now	Buy iTrixx-WFMN-Di Now
