iTrixx-WFMN-Di Equipment Hour Meter

iTrixx® Machine Hour Meter

Cost-effective

Data Security

Flexible Data Acquisition

Built-in MQTT Protocol & CAN Interface

Hardware and software for installation & data monitoring are included, no monthly fees

iTrixx is NOT a cloud based system, all data is stored locally at your facility

Additional to the hour counting, other sensors and devices can be connected to the iTrixx through its inputs

Enable iTrixx to reliably transfer data across networks with any IoT platforms and applications

DataCollector Desktop AppMonitor Machine Usage, Uptime/Downtime, Idle Time, Operation Counter

iTrixx Runtime Meter for Stationary Machine Preventative Maintenance

Companies with limited budgets and older equipment often find themselves facing a challenge: how to automate data collection process without replacing all their existing machinery or paying monthly fees for machine preventive maintenance? Manual methods and processed have gone as far as they can to achieve the goal. Data entry is a tedious, boring task that is often put off for as long as possible. Manually collected data is inaccurate, human error is inevitable.

Machine Preventative Maintenance Becomes Simpler and More Affordable with iTrixx Industrial Machine Monitoring

Machinery and electrical equipment such as CNC machine, generator, motors, pumps, compressors, and compost turners are critical to process manufacturing and many other business applications. For example, motor is the leading source of power consumption in many facilities, so technicians need to know specifics such as pump and motor runtime during maintenance. iTrixx Runtime Meter is the ideal way to monitor this equipment and is also an excellent productivity indicator.

Ultra 300 Eithernet IO Controller
Linortek iTrixx Hour Meter Architecture Diagram Visualization

What to Monitor

  • Machine usage

  • Machine uptime/downtime

  • Operation counter

  • Machine idle time

  • Machine vibration

The Key Features

The iTrixx equipment hour meter is a self-contained, WiFi/Ethernet enabled, custom developed device that can be used on all types of equipment to monitor the usage, temperature, voltage and more. With the iTrixx equipment hour meter, you can connect your offline equipment to the Internet and collect the equipment runtime data over a network or the Internet. You get accurate, instantaneous readings of your equipment with a simple click – without getting out of your chair. You can ensure proper maintenance and receive notifications when service is required, eliminating the need to physically visit equipment to collect data. It’s a simple, reliable and affordable solution for industrial, manufacturing, and equipment rental companies to collect runtime data for any equipment such as engines, motors, generators, pumps, manufacturing machinery and servers.

  • Collect Data Remotely

    • WiFi/Ethernet enabled with built-in web server, no 3rd party server and no monthly fees
    • Internet independent using your intranet
    • Record time from 0 to 999,999.99 hours
    • Two separate hour meters with independent triggers
    • Resettable hours for using with existing equipment
    • Built-in digital/analog inputs for data acquisition
    • Monitor multiple equipment runtime remotely from PC or mobile devices
  • Use Data with Ease

    • Automatic data report via email
    • Import the hour readings data in CSV file to your management software
    • Transfer the data automatically with the RESTful API
    • Use MQTT protocol to publish/scribe data to any IoT platforms and applications
    • Use relay output to signal alarm devices when maintenance required

Real-Time Data Acquisition

The iTrixx Hour Meter is built on Linortek’s existing TCP/IP web-based product platform, with digital inputs, relay outputs, analog inputs and a specially designed software that functions as an hour meter, no 3rd party server and no monthly fees, no need to manually collect runtime data from equipment, no more white board to update or tags to fill out, equipment operating hours can be read at any time from your PC or mobile devices,  receive email notification or audible/visual alerts when service is needed.
Linortek IoTMeter Flexible Data Collection and Access

The Products

iTrixx-WFMN-ADi wifi hour meter Equipment Wireless Hour Meter

Built-in web server, MQTT protocol, 2 relay outputs, 2 digital inputs, 2 analog inputs, 2 separate hour meters that can be triggered by power input, digital input or relay output, IP 66/67 enclosure, Wi-Fi connectivity.

iTrixx-WFMN-Di Equipment Hour Meter wifi hour meter

Built-in web server, MQTT protocol, 2 digital inputs, 2 separate hour meters that can be triggered by power input digital inputs, IP 66/67 enclosure, WiFi connectivity

Ultra 300 Ethernet IO Controller

Built-in web server, MQTT protocol, CAN interface, 2 digital inputs, 2 analog inputs, 2 relay outputs, 2 separate hour meters that can be triggered by power input digital inputs or relay output, DINRail Mountable enclosure, Ethernet connectivity.

iTrixx-NHM Equipment Hour Meter

Built-in web server, 2 digital inputs, 2 relay outputs, 2 separate hour meters that can be triggered by power input digital inputs or relay output, DINRail Mountable enclosure, Ethernet connectivity.

iTrixx WFMN-C Machine Hour Meter with Current Transformer

This is a custom kit that includes one iTrixx-WFMN-ADi unit with a current sensor to activate the meter. With this kit, you can monitor the on/off status of your machine by clamping the sensor around the AC wire of the three-phase power wires. It can be mounted either inside or outside of your machine’s control cabinet, there is no need for any modification of your machine’s wiring.

iTrixx WFMN ADI Machine Hour Meter with Current Transformer

This is a custom kit that includes one iTrixx-WFMN-ADi unit with a power transformer to activate the meter. With this kit, you can monitor the on/off status of your machine by plugging the power transformer to the same power source of the machine. It can be mounted either inside or outside of your machine’s control cabinet, there is no need for any modification of your machine’s wiring.

iTrixx WFMN-T Machine Hour Meter with Temperature Sensor

This is a custom kit that includes one iTrixx-WFMN-ADi unit with a thermocouple to activate the meter for the equipment such as HVAC, heater runtime monitoring. With this kit, you can put the thermocouple in front of the fan, when it detects the heat from the equipment, it starts counting, there is no need for any modification of your machine’s wiring.

WiFi Hour Meter vs Network Hour Meter

The WiFi Hour Meter connects to the LAN through WiFi. Once the equipment passes the WiFi connection points, it will automatically connect and report its current runtime data. Looking for a cost-effective solution for your stationary equipment such as machinery, pumps, generators? We have you covered! Check our Network Hour Meter,  or check the device comparison chart below to pick a right product for your project.

ModeliTrixx-Ultra 300iTrixx-NHMiTrixx-WFMN-ADiiTrixx-WFMN-Di
Part Number01-910-00111 01-910-00024 01-910-00060 01-910-00064
Web ServerBuilt- In (All Software Located on Built-in Web Server)
Built- In (All Software Located on Built-in Web Server)
Built- In (All Software Located on Built-in Web Server)
Built- In (All Software Located on Built-in Web Server)
Relay Outputs2 Signal Relay(2 Form C (1A @ 30VDC,
0.3A @ 125VAC)
2 (1 FORM A 110/220V 10A)2 Signal Relay(2 Form C (1A @ 30VDC,
0.3A @ 125VAC)
NA
Digital Inputs

2 (5-24 VDC)2 (5-24 VDC)2 (5-24 VDC)2 (5-24 VDC)
Analog Inputs2 (Non-isolated 0-5V)1 (for Temp&Humid only)2 (Non-isolated 0-5V)NA
Record Time (hrs)0 – 999,999.990 – 999,999.990 – 999,999.990 – 999,999.99
Data IntegrationUDP, RESTful API, XML, JSON, UDP, MQTTUDP, RESTful API, XML
JSON, UDP, MQTTJSON, UDP, MQTT
Data MonitoringLocal or RemoteLocal or RemoteLocal or RemoteLocal or Remote
Maintenance AlarmsEmail (SSL)/Audible, Visible (Signal
Device Required)
Email, Audible, Visible (Signal Device
Required)
Email (SSL)/Audible, Visible (Signal
Device Required)
Email (SSL email supported)
Power Input12VDC or POE12VDC or POE12-48VDC12-48VDC
EnclosureDIN Rail MountableDIN Rail MountableIP66/67 Polycarbonate BoxIP66/67 Polycarbonate Box
CertificationsNANAFCC, CE and ROHSFCC, CE and ROHS
Network ConnectivityEthernetEthernetWi-Fi (802.11 b/g/n)Wi-Fi (802.11 b/g/n)
CAN InterfaceYesNoNoNo
